Hydraulic Tube Assemblies

Five decades of tube bending excellence

Our Capabilities Include

  • Single and Double Flaring

  • Parflange ORFS

  • Brazed ORFS

  • Internal / External Threading

  • Custom Milling and Drilled Holes

  • Saddle Port Fittings

  • Expand / Reduce OD

  • Custom Brazed Ends

  • Manifold Block Centers

  • Hose / Tube Hybrids

  • Laser Marking

  • J2044 and SAE Beaded Ends

  • Metric DIN Connections

  • Expansive Plating Options

  • Ultraclean Pellet System for Debris Removal

  • Gravimetric Testing and Certifications

  • 3D Vector Analysis

  • Prototyping and Design Assistance



Tube Fabrication

Tube Fabrication

Tube Fabrication
Search video...
Carousel Brazing with a 70kW Inductance Brazer

Carousel Brazing with a 70kW Inductance Brazer

00:39
Play Video
HFI Fluid Power Products   Tube Bending on an Eaton Leonard VB50

HFI Fluid Power Products Tube Bending on an Eaton Leonard VB50

01:00
Play Video
High Speed Flaring

High Speed Flaring

00:10
Play Video
3D Vector Analysis

3D Vector Analysis

00:30
Play Video

HFI Fluid Power Products Advantages

Plating Solutions

Extreme Plating Solutions

Looking for RoHS Plating That Exceeds 96 Hours?

HFI Has You Covered

  • Hi-Corr Blue - clear (not blue in color) zinc, no rust after 120 hours

  • JDM F19 Spec - no rust after 120 hours

  • Chroma Seal K - exterior coating applied after zinc plating / up to 1000 hours no rust

Gravimetric Laboratory

Gravimetrics

The HFI Fluid Power Products' gravimetric laboratory can verify the cleanliness level of the hose, tube and fitting product you purchase. Certification reporting can detail the contaminant mass present, as well as maximum particle size.

Brazing Machine

Inductance Brazing

Silver inductance brazing is accomplished through the use of two high power units (30kW and 70 kW). An endless variety of adapters are available to terminate the ends of custom tube assemblies we produce.

Complex Custom Hydraulic Tubes

Complex Assemblies

Tube assemblies with complex secondary operations, such as drilling spray holes, grinding grooves, dimpled ends or other unusual properties are no problem for us. HFI Fluid Power Products has a secondary process facility comprised of a vast range of equipment to create rare configurations.

Hydraulic Tube Assemblies

Buying Power

HFI Purchases Tubing in Mill Run Quantities to Secure the Best Pricing and Availability

J356 / J524 / J525 / J527 / 304 / 316 / DOM

ASTM / Copper / 6061 / And More...

Chat, email or call

us now for a quote

(800) 822-6122

sales@hfi.us.com

Use our chat feature at the bottom

right. We love talking with our

customers!

HFI Fluid Power Products has been fabricating custom hydraulic tube assemblies since 1970. We have wide-ranging capabilities and offer competitive pricing. Most importantly, you won't have to wait days or weeks to get a quote back from our specialists- many tubes can be quoted same day. We are the experts when it comes to tubes.

HFI Fluid Power Products can quote runs of any size, including prototype lots.

Special packaging, kitting and labeling is available.

We can supply material certs, conformance certs, all levels of PPAPS and FSIR's, RoHS compliance statements, 3TG compliance statements and other documentation- just request the forms you need when placing your RFQ with our team.

HFI Fluid Power Products is an ISO 9001 registered company, and all processes utilized to fabricate custom product are audited for optimized product realization.

Custom Hydraulic Tube Assembly
Custom Tube Assemby
Custom Tube Assembly
Custom Hydraulic Tube
Hydraulic Tube End
Custom Made Hydraulic Tube Assembly

Let's Quote Your Tube Assembly Project Now

Our team of fluid power specialists are standing by right now, ready to assist you in procuring quality American made tube assemblies. Send us your prints, drawings or sketches and we will get to work for you.
